Detached Garages, Shops and Accessory Buildings
Design and permit drawings for detached garages, workshops and other accessory buildings on residential properties.
Is this you?
- You are building a detached garage
- You want a workshop or shop
- You are building a larger shed or a pool house
- You are planning a garage with a residential unit above
- It is already built without a permit

Accessory buildings are shaped by zoning as much as by construction. Matters that may need consideration include setbacks, lot coverage and building height. A garage with a residential unit above is a different kind of project: whether a unit is allowed depends on the property and the municipality, so see Secondary Suites and Additional Residential Units first.
Garage drawings

Front and rear elevations with vertical steel cladding and a tall overhead door. Open full size: Front and rear elevations of a detached garage with vertical steel cladding and an overhead door (opens in a new tab)
Side elevations showing the covered porch along one side. Open full size: Side elevations of a detached garage with a covered porch, window and overhead door (opens in a new tab)
Building section with the roof pitch, tall wall framing, slab and footings. Open full size: Building section of a detached garage with a 4:12 roof, tall wall framing, slab and footings (opens in a new tab)
Wall section from the metal roofing and steel cladding down to the foundation wall and weeping tile. Open full size: Wall section detail of a garage from metal roofing and steel cladding down to the foundation wall and weeping tile (opens in a new tab)
What’s included
- Site plan
- Foundation plan
- Floor plan
- Elevations
- Building section
- Typical construction details

Not included or separately scoped
- Where engineered roof trusses, floor systems or other specialized structural components are required, Neo-Scenic can coordinate the relevant supplier or engineer documentation with the building permit drawings.
- Engineering, where required. We can help coordinate with qualified engineering professionals; engineering services are scoped and quoted separately.
- Surveys, where required.
- Permit application management (optional)
- Permit application management is an optional service you can add to your design and drawing work. Drawing preparation and application submission are separate steps. Submitting an application does not guarantee municipal approval.
How it works
Initial conversation
We discuss your project and identify any zoning or municipal requirements that may need further review.
Site visit, where needed
By appointment, we measure and document the existing conditions. If a visit is needed to assess the project before quoting, it is billed separately. Where applicable, any credit for the visit toward subsequent design services will be confirmed in your written quotation.
Written quote
We provide a written quote outlining the proposed scope and fees before drawing work begins.
Preliminary design
You review the proposed layout. This stage typically includes up to three rounds of revisions. Changes after you approve the concept may involve additional fees.
Permit drawings
We prepare the drawing set and supporting documents for your permit application. Reasonable drawing revisions arising from municipal review are included.
Submitting the application
We guide you through what your project needs and prepare the drawings and documents. If you would like us to submit the application and coordinate with the municipality for you, we offer that as an optional additional service.
The full processAlready built without a permit?
If a garage, shop or other accessory building was built without a permit, we can review it and advise whether drawings for a permit application make sense. The municipality may require finished work to be opened up, tested or changed, and decides on the application.
Retroactive building permitsQuestions
Do I need a permit for a garage or shed?
Many accessory buildings need a building permit, and zoning limits such as setbacks, lot coverage and height apply to most of them. The limits vary by municipality and property, so check with your building department or contact us.
Can you submit the permit application for me?
Yes, as an optional service. Preparing the drawings and submitting the application are separate steps. If you would like us to submit the application and coordinate with the municipality, we quote that separately. Submitting an application does not guarantee approval.
